MEZZANINE FIVES

Supply and installation of a double-height mezzanine composed of load-bearing elements in galvanized, welded and bolted metal carpentry, including a metal staircase with handrail.

TECHNICAL SPECIFICATIONS of the supply:

• dimensions: approx. 4.94×4.035 m + 9.33×1.515 m
• total surface area: approx. 20 m² +15 m² + ladder
• height: approx. 4.4 m – 3.6 m
• treatments: hot-dip galvanizing according to UNI EN ISO 1461:2009
• tie rods: foundation tie rods for connection to the foundation.
• ladder: metal ladder with mesh steps made with 25×2 plate and handrail made with Φ40 H =1.1 m L=12 m tubes
• mezzanine parapet: Φ40 H =1.1 m L=7.3 m
• mezzanine floor: in embossed sheet metal/Orsogrill
